Description
Quick Specifications
|
|
|
|
|
|
|
|
|
|
|
|
Manufacturer Specifications
|
General Specifications |
|
| Platform | Boxed Processor |
| Market Segment | Mainstream Desktop |
| Product Family | AMD Ryzenâ„¢ Processors |
| Product Line |
AMD Ryzenâ„¢ 5 5000 G-Series Desktop Processors with Radeonâ„¢ Graphics |
| Consumer Use | Yes |
| Commercial Use | No |
| Regional Availability | Global, China, NA, EMEA, APJ, LATAM |
| Former Codename | “Cezanne” |
| Architecture | “Zen 3” |
| # of CPU Cores | 6 |
| Multithreading (SMT) | Yes |
| # of Threads | 12 |
| Max. Boost Clock | Up to 4.6GHz |
| Base Clock | 3.6GHz |
| L1 Cache | 384KB |
| L2 Cache | 3MB |
| L3 Cache | 16MB |
| Default TDP | 65W |
| AMD Configurable TDP (cTDP) | 45-65W |
| Processor Technology for CPU Cores | TSMC 7nm FinFET |
| CPU Compute Die (CCD) Size | 180mm² |
| Package Die Count | 1 |
| Unlocked for Overclocking | Yes |
| CPU Socket | AM4 |
| Thermal Solution (PIB) | AMD Wraith Stealth |
| Thermal Solution (MPK) | AMD Wraith Stealth |
| Max. Operating Temperature (Tjmax) | 95°C |
| Launch Date | 1/8/2024 |
| *OS Support | Windows 11 – 64-Bit Edition |
| Windows 10 – 64-Bit Edition | |
| RHEL x86 64-Bit | |
| Ubuntu x86 64-Bit | |
| *Operating System (OS) support will vary by manufacturer. | |
| Connectivity | |
| PCI Express® Version | PCIe® 3.0 |
| NVMe Support | Boot, RAID0, RAID1, RAID10 |
| System Memory Type | DDR4 |
| Memory Channels | 2 |
| Max. Memory | 128GB |
| System Memory Subtype | UDIMM |
| System Memory Specification | Up to 3200MT/s |
| Max Memory Speed | |
| 2x1R | |
| DDR4-3200 | |
| 2x2R | |
| DDR4-3200 | |
| 4x1R | |
| DDR4-2933 | |
| 4x2R | |
| DDR4-2667 | |
| Graphics Capabilities | |
| Integrated Graphics | Yes |
| Graphics Model | Radeonâ„¢ Graphics |
| Graphics Core Count | 7 |
| Graphics Frequency | 1900 MHz |
| Product IDs | |
| Product ID Boxed | 100-100001488BOX |
| Product ID Tray | 100-000001488 |
| Product ID MPK | 100-100001488MPK |
based on 774 ratingsThis score is based on all expert and user reviews that TestFreaks has collected for this product. Reviews and scores are collected from more than 30 countries but only reviews in selected languages are shown below.
| 5 | ☆ | |
| 4 | ☆ | |
| 3 | ☆ | |
| 2 | ☆ | |
| 1 | ☆ |
(Experts)
| 5 | ☆ | |
| 4 | ☆ | |
| 3 | ☆ | |
| 2 | ☆ | |
| 1 | ☆ |
(Users)
- Expert Reviews (1)
- User Reviews (32)
- Write Review
Powered by TestFreaks
RY
i received the product as described, I eagerly took the old CPU out of the motherboard and inserted the new CPU, to my dismay nothing happened, I took the new CPU off the board and inserted the old CPU, the pc wouldn’t turn on. I tried a second motherbaord and the same thing happened. So I never got to use the CPU, it looked like the 1. Motherboard packed up when I inserted the new CPU and nuked it or 2. The new CPU was faulty and nuked the motherboard.
Either way I had to buy a new motherboard and a new CPU, which is working perfectly.
Easy to install
dont know if was DOA or not, cant prove either.
