Description
Quick Specifications
|
|
|
|
|
|
|
|
|
|
|
|
Manufacturer Specifications
|
Platform
|
Desktop
|
|
Product Family
|
AMD Ryzenâ„¢ Processors
|
|
Product Line
|
AMD Ryzenâ„¢ 7 8000 G-Series Desktop
Processors with Radeonâ„¢ Graphics |
|
AMD PRO Technologies
|
No
|
|
Consumer Use
|
Yes
|
|
Regional Availability
|
Global
|
|
Former Codename
|
“Phoenix”
|
|
Architecture
|
“Zen 4”
|
|
# of CPU Cores
|
8
|
|
Multithreading (SMT)
|
Yes
|
|
# of Threads
|
16
|
|
Max. Boost Clock
|
Up to 5.1GHz
|
|
Base Clock
|
4.2GHz
|
|
L2 Cache
|
8MB
|
|
L3 Cache
|
16MB
|
|
Default TDP
|
65W
|
|
AMD Configurable TDP (cTDP)
|
45-65W
|
|
Processor Technology for CPU Cores
|
TSMC 4nm FinFET
|
|
CPU Compute Die (CCD) Size
|
178mm²
|
|
Package Die Count
|
1
|
|
Unlocked for Overclocking
|
Yes
|
|
AMD EXPOâ„¢ Memory Overclocking
Technology |
Yes
|
|
Precision Boost Overdrive
|
Yes
|
|
Curve Optimizer Voltage Offsets
|
Yes
|
|
AMD Ryzenâ„¢ Master Support
|
Yes
|
|
CPU Socket
|
AM5
|
|
CPU Boost Technology
|
Precision Boost 2
|
|
Instruction Set
|
x86-64
|
|
Supported Extensions
|
AES, AMD-V, AVX, AVX2, AVX512, FMA3,
MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
|
Max. Operating Temperature (Tjmax)
|
95°C
|
|
*OS Support
|
Windows 11 – 64-Bit Edition
|
|
Windows 10 – 64-Bit Edition
|
|
|
RHEL x86 64-Bit
|
|
|
Ubuntu x86 64-Bit
|
|
|
*Operating System (OS) support will vary by manufacturer.
|
|
|
Native USB 4 (40Gbps) Ports
|
2
|
|
Native USB 3.2 Gen 2 (10Gbps) Ports
|
2
|
|
Native USB 2.0 (480Mbps) Ports
|
1
|
|
PCI Express® Version
|
PCIe® 4.0
|
|
Native PCIe® Lanes (Total/Usable)
|
20 / 16
|
|
NVMe Support
|
Boot, RAID0, RAID1
|
|
System Memory Type
|
DDR5
|
|
Memory Channels
|
2
|
|
Max. Memory
|
256GB
|
|
System Memory Subtype
|
UDIMM
|
|
Max Memory Speed
|
2x1R: DDR5-5200
|
|
2x2R: DDR5-5200
|
|
|
4X1R: DDR5-3600
|
|
|
4x2R: DDR5-3600
|
|
|
Integrated Graphics
|
Yes
|
|
Graphics Model
|
AMD Radeonâ„¢ 780M
|
|
Graphics Core Count
|
12
|
|
Graphics Frequency
|
2900 MHz
|
|
DirectX® Version
|
12
|
|
DisplayPortâ„¢ Version
|
2.1
|
|
DisplayPort Extensions
|
HDR Metadata
|
|
Adaptive-Sync
|
|
|
UHBR10
|
|
|
DisplayPort Max Refresh Rates (SDR)
|
7680×4320 @ 60Hz
|
|
3840×2160 @ 240Hz
|
|
|
3440×1440 @ 360Hz
|
|
|
2560×1440 @ 480Hz
|
|
|
1920×1080 @ 600Hz
|
|
|
DisplayPort Max Refresh Rates (HDR)
|
7680×4320 @ 60Hz
|
|
3840×2160 @ 240Hz
|
|
|
3440×1440 @ 360Hz
|
|
|
2560×1440 @ 480Hz
|
|
|
1920×1080 @ 600Hz
|
|
|
HDMI® Version
|
2.1
|
|
HDCP Version Supported
|
2.3
|
|
USB Type-C® DisplayPort™ Alternate Mode
|
Yes
|
|
Multi-Monitor Support
|
Yes
|
|
Max Displays
|
4
|
|
AMD FreeSyncâ„¢
|
Yes
|
|
Wireless Display
|
Miracast
|
|
Max Video Encode Bandwidth (SDR)
|
1080p630 8bpc H.264
|
|
1440p373 8bpc H.264
|
|
|
2160p175 8bpc H.264
|
|
|
1080p630 8bpc H.265
|
|
|
1440p373 8bpc H.265
|
|
|
2160p175 8bpc H.265
|
|
|
4320p43 8bpc H.265
|
|
|
1080p864 8/10bpc AV1
|
|
|
1440p513 8/10bpc AV1
|
|
|
2160p240 8/10bpc AV1
|
|
|
4320p60 8/10bpc AV1
|
|
|
Max Video Decode Bandwidth
|
1080p60 8bpc MPEG2
|
|
1080p60 8bpc VC1
|
|
|
1080p786 8/10bpc VP9
|
|
|
2160p196 8/10bpc VP9
|
|
|
4320p49 8/10bpc VP9
|
|
|
1080p1200 8bpc H.264
|
|
|
2160p300 8bpc H.264
|
|
|
4320p75 8bpc H.264
|
|
|
1080p786 8/10bpc H.265
|
|
|
2160p196 8/10bpc H.265
|
|
|
4320p49 8/10bpc H.265
|
|
|
1080p960 8/10bpc AV1
|
|
|
2160p240 8/10bpc AV1
|
|
|
4320p60 8/10bpc AV1
|
|
|
AMD SmartAccess Memory
|
Yes
|
|
Brand Name
|
AMD Ryzenâ„¢ AI
|
|
AMD Ryzenâ„¢ AI
|
Available
|
|
Performance
|
Up to 16 TOPS
|
|
Product IDs
|
|
|
Product ID Boxed
|
100-100001236BOX
|
|
Product ID Tray
|
100-000001236
|
|
Product ID MPK
|
100-100001236MPK
|
|
Security, Virtualization, and Manageability
|
|
|
AMD Enhanced Virus Protection (NX bit)
|
Yes
|
