Description
Quick Specifications
|
|
|
|
|
|
|
|
|
Manufacturer Specifications
| General Specifications | |
|
Platform
|
Desktop
|
|
Product Family
|
AMD Ryzenâ„¢ PRO Processors
|
|
Product Line
|
AMD Ryzenâ„¢ Threadripperâ„¢ PRO 7000
WX-Series |
|
AMD PRO Technologies
|
Yes
|
|
Commercial Use
|
Yes
|
|
Regional Availability
|
Global
|
|
Former Codename
|
“Storm Peak”
|
|
Architecture
|
“Zen 4”
|
|
# of CPU Cores
|
24
|
|
Multithreading (SMT)
|
Yes
|
|
# of Threads
|
48
|
|
Max. Boost Clock
|
Up to 5.3GHz
|
|
Base Clock
|
4.2GHz
|
|
L1 Cache
|
1.5MB
|
|
L2 Cache
|
24MB
|
|
L3 Cache
|
128MB
|
|
Default TDP
|
350W
|
|
Processor Technology for CPU Cores
|
TSMC 5nm FinFET
|
|
Processor Technology for I/O Die
|
TSMC 6nm FinFET
|
|
CPU Compute Die (CCD) Size
|
71mm²
|
|
I/O Die (IOD) Size
|
388mm²
|
|
Package Die Count
|
5
|
|
Unlocked for Overclocking
|
Yes
|
|
AMD EXPOâ„¢ Memory Overclocking
Technology |
Yes
|
|
Precision Boost Overdrive
|
Yes
|
|
Curve Optimizer Voltage Offsets
|
Yes
|
|
CPU Socket
|
sTR5
|
|
Supporting Chipsets
|
WRX90
|
|
TRX50
|
|
|
Pro 695
|
|
|
CPU Boost Technology
|
Precision Boost 2
|
|
Instruction Set
|
x86-64
|
|
Supported Extensions
|
AES, AMD-V, AVX, AVX2, AVX512, FMA3,
MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
|
Thermal Solution (PIB)
|
Not included
|
|
Thermal Solution (MPK)
|
NA
|
|
Max. Operating Temperature (Tjmax)
|
95°C
|
|
Launch Date
|
10/19/2023
|
|
*OS Support
|
Windows 11 – 64-Bit Edition
|
|
RHEL x86 64-Bit
|
|
|
Ubuntu x86 64-Bit
|
|
|
*Operating System (OS) support will vary by manufacturer.
|
|
|
Connectivity
|
|
|
USB Type-C® Support
|
No
|
|
Native USB 3.2 Gen 2 (10Gbps) Ports
|
4
|
|
Native SATA Ports
|
4
|
|
PCI Express® Version
|
PCIe 5.0
|
|
PCIe® Lanes (Total/Usable/PCIe® 5.0)
|
148 / 144 / 128
|
|
NVMe Support
|
Boot, RAID0, RAID1, RAID10, RAID5
|
|
System Memory Type
|
DDR5
|
|
Memory Channels
|
8
|
|
System Memory Subtype
|
RDIMM
|
|
System Memory Specification
|
Up to 5200MT/s
|
|
ECC Support
|
Yes (Default Enabled)
|
|
Graphics Capabilities
|
|
|
Integrated Graphics
|
No
|
|
Graphics Model
|
Discrete Graphics Card Required
|
|
USB Type-C® DisplayPort™ Alternate Mode
|
n/a
|
|
Product IDs
|
|
|
Product ID Boxed
|
100-100000885WOF
|
|
Product ID Tray
|
100-000000885
|
|
Key Features
|
|
|
Supported Technologies
|
AMD EXPOâ„¢ Technology
|
|
AMD PRO technologies
|
|
|
AMD Ryzenâ„¢ Technologies
|
