Description
Quick Specifications
|
|
|
|
|
|
|
|
|
|
|
|
Manufacturer Specifications
|
General Specifications |
|
| Platform | Desktop |
| Product Family | AMD Ryzenâ„¢ Processors |
| Product Line |
AMD Ryzenâ„¢ 5 8000 G-Series Desktop Processors with Radeonâ„¢ Graphics |
| AMD PRO Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | “Phoenix” |
| Architecture | 2 x “Zen4”, 4 x “Zen4c” |
| # of CPU Cores | 6 |
| Multithreading (SMT) | Yes |
| # of Threads | 12 |
| Max. Boost Clock | Up to 5.0GHz |
| Max Zen4c Clock | Up to 3.7GHz |
| Base Clock | 3.5GHz |
| Zen4 Base Clock | 4.1GHz |
| Zen4c Base Clock | 3.2GHz |
| L2 Cache | 6MB |
| L3 Cache | 16MB |
| Default TDP | 65W |
| AMD Configurable TDP (cTDP) | 45-65W |
| Processor Technology for CPU Cores | TSMC 4nm FinFET |
| 137mm² | |
| Package Die Count | 1 |
| AMD EXPOâ„¢ Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzenâ„¢ Master Support | Yes |
| CPU Socket | AM5 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions |
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Max. Operating Temperature (Tjmax) | 95°C |
| *OS Support | Windows 11 – 64-Bit Edition |
| Windows 10 – 64-Bit Edition | |
| RHEL x86 64-Bit | |
| Ubuntu x86 64-Bit | |
| *Operating System (OS) support will vary by manufacturer. | |
| Connectivity | Native USB 4 (40Gbps) Ports |
| 2 | |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 2 |
| Native USB 2.0 (480Mbps) Ports | 1 |
| PCI Express® Version | PCIe® 4.0 |
| Native PCIe® Lanes (Total/Usable) | 14 / 10 |
| NVMe Support | Boot, RAID0, RAID1 |
| System Memory Type | DDR5 |
| Memory Channels | 2 |
| Max. Memory | 256GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed | 2x1R |
| DDR5-5200 | |
| 2x2R | |
| DDR5-5200 | |
| 4X1R | |
| DDR5-3600 | |
| 4x2R | |
| DDR5-3600 | |
| Graphics Capabilities | |
| Integrated Graphics | Yes |
| Graphics Model | AMD Radeonâ„¢ 740M |
| Graphics Core Count | 4 |
| Graphics Frequency | 2800 MHz |
| DirectX® Version | 12 |
| DisplayPortâ„¢ Version | 2.1 |
| DisplayPort Extensions | HDR Metadata |
| Adaptive-Sync | |
| UHBR10 | |
| DisplayPort Max Refresh Rates (SDR) | 7680×4320 @ 60Hz |
| 3840×2160 @ 240Hz | |
| 3440×1440 @ 360Hz | |
| 2560×1440 @ 480Hz | |
| 1920×1080 @ 600Hz | |
| DisplayPort Max Refresh Rates (HDR) | 7680×4320 @ 60Hz |
| 3840×2160 @ 240Hz | |
| 3440×1440 @ 360Hz | |
| 2560×1440 @ 480Hz | |
| 1920×1080 @ 600Hz | |
| HDMI® Version | 2.1 |
| HDCP Version Supported | 2.3 |
| USB Type-C® DisplayPort™ Alternate Mode | Yes |
| Multi-Monitor Support | Yes |
| Max Displays | 4 |
| AMD FreeSyncâ„¢ | Yes |
| Wireless Display | Miracast |
| Max Video Encode Bandwidth (SDR) | 1080p630 8bpc H.264 |
| 1440p373 8bpc H.264 | |
| 2160p175 8bpc H.264 | |
| 1080p630 8bpc H.265 | |
| 1440p373 8bpc H.265 | |
| 2160p175 8bpc H.265 | |
| 4320p43 8bpc H.265 | |
| 1080p864 8/10bpc AV1 | |
| 1440p513 8/10bpc AV1 | |
| 2160p240 8/10bpc AV1 | |
| 4320p60 8/10bpc AV1 | |
| Video Encode (HDR) | 1080p60 8bpc MPEG2 |
| 1080p60 8bpc VC1 | |
| 1080p786 8/10bpc VP9 | |
| 2160p196 8/10bpc VP9 | |
| 4320p49 8/10bpc VP9 | |
| 1080p1200 8bpc H.264 | |
| 2160p300 8bpc H.264 | |
| 4320p75 8bpc H.264 | |
| 1080p786 8/10bpc H.265 | |
| 2160p196 8/10bpc H.265 | |
| 4320p49 8/10bpc H.265 | |
| 1080p960 8/10bpc AV1 | |
| 2160p240 8/10bpc AV1 | |
| 4320p60 8/10bpc AV1 | |
| AMD SmartAccess Memory | Yes |
| Product IDs | |
| Product ID Boxed | 100-100000931BOX |
| Product ID Tray | 100-000001491 |
| 100-000000931 | |
| Product ID MPK | 100-100000931MPK |
| Security, Virtualization, and Manageability | |
| AMD Enhanced Virus Protection (NX bit) | Yes |
