Description
Quick Specifications
|
|
|
Manufacturer Specifications
|
FAN Specification
|
|
|
Size
|
92x92x14 mm |
|
Mounting hole
spacing |
82,5×82,5 mm |
|
Connector & pin-configuration
|
4-pin PWM |
|
Cable length
|
20cm + 30cm NA-EC1 extension cable |
|
Bearing
|
SSO2 |
|
Blade geometry
|
A-Series with Flow Acceleration Channels |
|
Frame technology
|
AAO (Advanced Acoustic Optimisation) |
|
Rotational speed
(+/- 10%) |
2200 RPM |
|
Rotational speed
with L.N.A. (+/- 10%) |
1700 RPM |
|
Min. rotational
speed @ 20% PWM (+/-20%) |
500 RPM |
|
Airflow
|
50,5 m³/h |
|
Airflow with L.N.A.
|
38,1 m³/h |
|
Acoustical noise
|
19,9 dB(A) |
|
Acoustical noise
with L.N.A. |
13,5 dB(A) |
|
Static pressure
|
1,64 mm Hâ‚‚O |
|
Static pressure
with L.N.A. |
0,92 mm Hâ‚‚O |
|
Input power
(typical) |
1,32 W |
|
Input power
(max.) |
1,32 W |
|
Input current
(typical) |
0,11 A |
|
Max. input
current |
0,11 A |
|
Operating
voltage |
12 V |
|
MTTF
|
> 150.000 h |
|
Scope of
delivery |
Low-Noise Adapter (L.N.A.) |
| 4-Pin Y-Cable | |
| 30cm Extension Cable | |
| 4 Vibration-Compensators | |
| 4 Fan Screws | |
|
Warranty
|
6 years |
