Description
Quick Specifications
|
|
|
Manufacturer Specifications
| Application For | |
|
Intel
|
LGA1851/1700/1200/115X/20XX
|
|
AMD
|
AM5/AM4
|
|
Product Dimensions |
144×147×164 mm(L×W×H) |
|
Heatsink Dimensions |
140×110×160 mm(L×W×H) |
|
Net Weight |
1772 g |
| Heatpipe | Ø6 mm×7 pcs |
|
Fan Dimensions |
140×140×25 mm(L×W×H) / 120×120×25 mm(L×W×H) |
|
Fan Speed (Performance Mode) |
500~1800 RPM±10% / 500~1700 RPM±10% |
|
Fan Airflow (Performance Mode) |
61.25 CFM / 58.06 CFM |
|
Fan Air Pressure (Performance Mode) |
3.76 mmAq / 2.1 mmAq |
|
Overall Noise (Performance Mode) |
≤29.3 dB(A) |
|
Fan Speed (Quiet Mode) |
500~1450 RPM±10% / 500~1350 RPM±10% |
|
Fan Airflow (Quiet Mode) |
48.55 CFM / 46.75 CFM |
|
Fan Air Pressure (Quiet Mode) |
2.46 mmAq / 1.35 mmAq |
|
Overall Noise (Quiet Mode) |
≤22.6 dB(A) |
|
Fan Connector |
4-pin PWM |
|
Bearing Type |
Fluid Dynamic Bearing |
|
Motor Type |
6-Pole Fan Motor |
|
Fan Rated Voltage |
12 VDC |
|
Fan Rated Current |
0.2 A / 0.2 A |
|
Fan Power Consumption |
2.4W / 2.4 W |
|
Rated Voltage |
12 VDC |
|
Power Consumption(Performance Mode) |
4.8 W |
|
Power Consumption(Quiet Mode) |
3.6 W |
| P/N | R-ASN4-BKNVNN-GJD |
