Description
Quick Specifications
| | |
Manufacturer Specifications
|
FAN Specification
| |
|
Size
| 92x92x14 mm |
|
Mounting hole spacing | 82,5×82,5 mm |
|
Connector & pin-configuration
| 4-pin PWM |
|
Cable length
| 20cm + 30cm NA-EC1 extension cable |
|
Bearing
| SSO2 |
|
Blade geometry
| A-Series with Flow Acceleration Channels |
|
Frame technology
|
AAO (Advanced Acoustic Optimisation) |
|
Rotational speed (+/- 10%) | 2200 RPM |
|
Rotational speed with L.N.A. (+/- 10%) | 1700 RPM |
|
Min. rotational speed @ 20% PWM (+/-20%) | 500 RPM |
|
Airflow
| 50,5 m³/h |
|
Airflow with L.N.A.
| 38,1 m³/h |
|
Acoustical noise
| 19,9 dB(A) |
|
Acoustical noise with L.N.A. | 13,5 dB(A) |
|
Static pressure
| 1,64 mm H₂O |
|
Static pressure with L.N.A. | 0,92 mm H₂O |
|
Input power (typical) | 1,32 W |
|
Input power (max.) | 1,32 W |
|
Input current (typical) | 0,11 A |
|
Max. input current | 0,11 A |
|
Operating voltage | 12 V |
|
MTTF
| > 150.000 h |
|
Scope of delivery | Low-Noise Adapter (L.N.A.) |
| 4-Pin Y-Cable | |
| 30cm Extension Cable | |
| 4 Vibration-Compensators | |
| 4 Fan Screws | |
|
Warranty
| 6 years |
