The NH-L9x65 is a highly compact, quiet low-profile cooler designed for use in small form factor cases and HTPC environments. While it provides first-rate performance in its class, it is not suitable for overclocking and or CPUs that create high heat loads. Please consult our CPU compatibility list to find out whether the NH-L9x65 is recommended for your CPU. |
|
Cooler Specification
|
Socket compatibility
|
|
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4 |
(Current socket compatibility applies to all coolers purchased since Q4 2021. For older coolers, please refer to this chart.) |
|
Height (without
fan) |
51 mm |
|
Width (without
fan) |
95 mm |
|
Depth (without
fan) |
95 mm |
|
Height (with
fan) |
65 mm |
|
Width (with fan)
|
95 mm |
|
Depth (with fan)
|
95 mm |
|
Weight (with
fan) |
413 g |
|
Material
|
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
|
NSPR
|
67 |
|
Max. TDP
|
see NSPR |
|
Fan
compatibility |
92x92x14, 92x92x25 |
|
Scope of
delivery |
NF-A9x14 PWM premium fan |
| NA-RC7 Low-Noise Adaptor (L.N.A.) | |
| NT-H1 high-grade thermal compound | |
| SecuFirm2â„¢ Mounting Kit | |
| Noctua Metal Case-Badge | |
|
Warranty
|
6 Years |
|
FAN Specification
|
|
|
Model
|
Noctua NF-A9x14 PWM |
|
Bearing
|
SSO2 |
|
Max. rotational
speed (+/- 10%) |
2500 RPM |
|
Max. rotational
speed with L.N.A. (+/- 10%) |
1800 RPM |
|
Min. rotational
speed @ 20% PWM (+/-20%) |
600 RPM |
|
Max. airflow
|
57,5 m³/h |
|
Max. airflow with L.N.A.
|
40,8 m³/h |
|
Max. acoustical
noise |
23,6 dB(A) |
|
Max. acoustical
noise with L.N.A. |
14,8 dB(A) |
|
Input power
(max.) |
2,52 W |
|
Voltage range
|
12 V |
|
MTTF
|
> 150.000 h |
