Description
Quick Specifications
|
|
|
Manufacturer Specifications
|
Cooler Specification
|
|
|
Socket compatibility
|
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4 |
|
(Current socket compatibility applies to all coolers purchased since Q4 2021. For older coolers, please refer to this chart.) |
|
|
Height (without
fan) |
110 mm |
|
Width (without
fan) |
95 mm |
|
Depth (without
fan) |
95 mm |
|
Height (with
fan) |
110 mm |
|
Width (with fan)
|
95 mm |
|
Depth (with fan)
|
95 mm |
|
Weight (with
fan) |
531 g |
|
Material
|
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
|
NSPR
|
88 |
|
Max. TDP
|
see NSPR |
|
Fan
compatibility |
92x92x25 |
|
Scope of
delivery |
NF-A9 PWM premium fan |
| NA-RC7 Low-Noise Adaptor (L.N.A.) | |
| NT-H1 high-grade thermal compound | |
| SecuFirm2â„¢ Mounting Kit | |
| Fan-clips for second NF-A9 | |
| Noctua Metal Case-Badge | |
|
Warranty
|
6 Years |
|
FAN Specification
|
|
|
Model
|
Noctua NF-A9 PWM |
|
Bearing
|
SSO2 |
|
Max. rotational
speed (+/- 10%) |
2000 RPM |
|
Max. rotational
speed with L.N.A. (+/- 10%) |
1550 RPM |
|
Min. rotational
speed @ 20% PWM (+/-20%) |
400 RPM |
|
Max. airflow
|
78,9 m³/h |
|
Max. airflow with L.N.A.
|
62,6 m³/h |
|
Max. acoustical
noise |
22,8 dB(A) |
|
Max. acoustical
noise with L.N.A. |
16,3 dB(A) |
|
Input power
(max.) |
1,2 W |
|
Voltage range
|
12 V |
|
MTTF
|
> 150.000 h |
