Description
| | |
| | |
| | |
| | |
| | |
| | |
| | |
| | |
| | |
| | |
| | |
| | |
| | |
|
SPECIFICATION
| |
|
Graphics Engine
|
AMD Radeon™ RX 9070 XT |
|
Model Name
|
RX9070XT 16G-L/OC |
|
Series
|
Hellhound
|
|
Stream Processor
|
4096 Units |
|
Video Memory
|
16GB GDDR6 |
|
Memory Speed
|
20.0 Gbps |
|
Memory Interface
|
256-bit
|
|
Engine Clock(OC)
|
up to 2460MHz(Game)¹ |
| up to 3010MHz(Boost)² | |
|
Engine Clock(STD/Silent) |
up to 2400MHz(Game)¹ |
| up to 2970MHz(Boost)² | |
|
Bus Standard
|
PCIE 5.0 x16 |
|
Standard Display Connectors |
1 x HDMI 2.1b，3 x DisplayPort 2.1a (only 2x simultaneous DP2.1 connections can be supported) |
|
Feature Support
| |
|
DirectX® Support
|
12
|
|
OpenGL
|
4.6
|
|
AMD Eyefinity Technology |
Support
|
|
AMD Stream Technology
|
Support
|
|
AMD Smart Access Memory
|
Support
|
|
Maximum Resolution
|
DisplayPort
|
|
7680×4320
| |
|
HDMI
|
7680×4320
|
|
Power Specs + Board Dimensions
|
Board Dimensions
|
|
327mm*128mm*49mm
| |
| 340mm*142mm*49mm(with bracket) | |
|
Slot
|
2.5
|
|
Minimum System Power requirement (W) |
800W³
|
|
Extension Power Connector |
Two 8-pin PCI Express Power connectors |
|
Remark
|
¹Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. |
|
²Boost Clock is the maximum frequency achievable on the GPU running a burstyworkload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to:thermal conditions and variation in applications and workloads. | |
|
³Recommended power supply for AMD Radeon RX 9070 XT graphics card is minimum 800W or greater power supply with 12V output > 75A. Minimum recommended system power supply wattage is based on a PC configured with an AMD Ryzen 9 7950X processor plus typical power requirements of other system components. Your system requirements may differ. |
| 5 | ☆ | |
| 4 | ☆ | |
| 3 | ☆ | |
| 2 | ☆ | |
| 1 | ☆ |
- User Reviews (33)
- Write Review
Couldn’t be happier with it. Undervolted it to -60mV, set max frequency to 2700 and modified the fan curve and temps never go above 55 degrees even when playing GPU demanding games such as Oblivion Remastered or KCD II. Runs most games at 150+ fps in 1440p with optimised settings (medium-ultra). FSR4 is excellent and frame generation is pretty decent in single player games as well.
•
Great card. Runs very good (hasn’t been over 63 degrees even at full load) Fans run quiet too. Best value for money 9070 XT
If you want a fancy colourful card with LED’s on the fans etc. this isn’t the card. (that stuff doesn’t worry me)
•
Card has coil whine which is very frustrating considering what other people say about the card. Wouldn’t have bought it if I had known as I have auditory issues that coil whine exacerbate.
Anything over 120fps causes it to start screaming.
