Description
Quick Specifications
|
|
|
|
|
|
|
|
|
Manufacturer Specifications
|
DISPLAY
|
|
|
Panel Type
|
Transmissive TFT, 262K color
|
|
Diagonal
|
1.54 in / 39.1 mm
|
|
Resolution
|
240 x 240 px
|
|
Refresh Rate
|
30 Hz
|
|
Brightness
|
300 cd/m²
|
|
Colors
|
18-bit
|
|
Orientation
|
Software adjustable
|
|
CPU SUPPORT
|
|
|
Intel®
|
Intel Core i9 / Core i7 / Core
i5 / Core i3 / Pentium / Celeron |
|
AMD®
|
AMD Ryzen 9 / Ryzen 7 / Ryzen
5 / Ryzen 3 |
|
PRODUCT INFO
|
|
|
Warranty
|
6 Years
|
| Model Number | RL-KR360-W2 |
| EAN | 5056547205267 |
|
PUMP
|
|
|
Name
|
NZXT Turbine
|
|
Motor Speed
|
1,200 – 2,800 ± 300 RPM
|
|
Power
|
12 V DC, 0.3 A
|
|
CAP
|
|
|
Diameter
|
2.87 in / 72.95 mm
|
|
Height
|
2.2 in / 55.97 mm
|
|
Housing Material
|
Plastic
|
|
COLD
PLATE |
|
|
Dimensions
|
56 mm x 56 mm
|
|
Type
|
Split flow
|
|
Material
|
Copper
|
|
TUBING
|
|
|
Length
|
420 mm
|
|
Material
|
CIIR rubber with Nylon braided
sleeve |
|
FAN
SPECS |
|
|
Model
|
F360 RGB Core (EV) Fan
|
|
Color
|
White
|
|
Dimensions
|
360 x 120 x 26 mm
|
|
Quantity
|
1
|
|
Speed
|
500 – 2,400 ± 250 RPM per fan
|
|
Airflow
|
75.05 CFM per fan
|
|
Static Pressure
|
3.07 mm-Hâ‚‚O per fan
|
|
Noise Level
|
31.9 dBA per fan
|
|
Power Consumption
|
12V DC, 0.79 A, 9.48 W | 5V
DC, 0.81 A, 4.05 W |
|
Connector
|
8-pin for PWM & RGB
|
|
Bearing
|
Fluid Dynamic Bearing
|
|
Lifespan
|
60,000 hours
|
|
LED Quantity
|
8 LEDs per fan
|
|
Cable Length
|
600 mm
|
|
Materials
|
Plastic, rubber, PCB
|
|
SOCKET
SUPPORT |
|
|
Intel®
|
LGA 1851/1700, 1200/115X
|
|
AMD®
|
AM5, AM4
|
