Description
Quick Specifications
|
|
|
Manufacturer Specifications
| Cooler Specification | |
|
Socket compatibility
|
Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4 |
| Height (without fan) | 145 mm |
| Width (without fan) | 125 mm |
| Depth (without fan) | 113 mm |
| Weight (without fan) | 700 g |
| Height (with fan) | 145 mm |
| Width (with fan) | 125 mm |
| Depth (with fan) | 113 mm |
| Weight (with fan) | 890 g |
|
Material
|
Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
| NSPR | 148 |
| Max. TDP | see NSPR |
| Fan compatibility | NF-A12x25r (square-frame 120mm fans not supported) |
|
Scope of delivery |
Black NH-D12L heatsink |
| NF-A12x25r PWM chromax.black premium fan | |
| NA-RC14 Low-Noise Adaptor (L.N.A) | |
| NT-H1 high-grade thermal compound | |
| Black SecuFirm2â„¢ mounting kit | |
| Noctua metal case-badge | |
|
Warranty
|
6 Years |
|
FAN Specification |
|
| Model | Noctua NF-A12x25r PWM chromax.black |
| Bearing | SSO2 |
| Max. rotational speed (+/- 10%) | 2000 RPM |
|
Max. rotational speed with L.N.A. (+/- 10%) |
1700 RPM |
|
Min. rotational speed @ 20% PWM (+/-20%) |
450 RPM |
| Max. airflow | 102,1 m³/h |
| Max. airflow with L.N.A. | 84,5 m³/h |
| Max. acoustical noise | 22,6 dB(A) |
| Max. acoustical noise with L.N.A. | 18,8 dB(A) |
| Airflow | 102.1 m³/h |
| Airflow with L.N.A. | 84.5 m³/h |
| Acoustical noise | 22.6 dB(A) |
| Input power (typical) | 1.2 W |
| Input power (max.) | 1.68 W |
| Voltage range | 12 V |
| MTTF | > 150.000 h |
