Description
Quick Specifications
|
|
|
Manufacturer Specifications
|
FAN Specification
|
|
|
Size
|
120x120x25 mm |
|
Mounting hole
spacing |
105×105 mm |
|
Connector & pin-configuration
|
4-pin PWM |
|
Cable length
|
20cm + 30cm NA-EC1 extension cable |
|
Bearing
|
SSO2 |
|
Blade geometry
|
S-Series with Anti-Stall Knobs |
|
Frame technology
|
AAO (Advanced Acoustic Optimisation) |
|
Rotational speed
(+/- 10%) |
1200 RPM |
|
Rotational speed
with L.N.A. (+/- 10%) |
900 RPM |
|
Min. rotational
speed @ 20% PWM (+/-20%) |
300 RPM |
|
Airflow
|
107,5 m³/h |
|
Airflow with L.N.A.
|
83,2 m³/h |
|
Acoustical noise
|
17,8 dB(A) |
|
Acoustical noise
with L.N.A. |
10,7 dB(A) |
|
Static pressure
|
1,19 mm Hâ‚‚O |
|
Static pressure
with L.N.A. |
0,73 mm Hâ‚‚O |
|
Input power
(typical) |
1,19 W |
|
Input power
(max.) |
1,44 W |
|
Input current
(typical) |
0,1 A |
|
Max. input
current |
0,12 A |
|
Operating
voltage |
12 V |
|
MTTF
|
> 150.000 h |
|
Scope of
delivery |
Low-Noise Adaptor (L.N.A.) |
| 4-Pin Y-Cable | 30cm Extension Cable |
| 4 Vibration-Compensators | |
| 4 Fan Screws | |
|
Warranty
|
6 years |
