Description
Quick Specifications
|
|
|
Manufacturer Specifications
|
Size
|
140x140x25 mm |
|
Mounting hole spacing
|
124.5×124.5 mm |
|
Connector
& pin-configuration |
4-pin PWM |
|
Cable length
|
20cm + 30cm NA-EC1 extension cable |
|
Bearing
|
SSO2 |
|
Blade geometry
|
A-Series with Flow Acceleration Channels |
|
Frame technology
|
AAO (Advanced Acoustic Optimisation) |
|
Material
|
Sterrox® LCP |
|
Rotational speed (+/- 10%)
|
1500 RPM |
|
Rotational speed with L.N.A. (+/-
10%) |
1250 RPM |
|
Airflow
|
155.6 m³/h |
|
Airflow with
L.N.A. |
127.1 m³/h |
|
Acoustical noise
|
24.8 dB(A) |
|
Acoustical noise with L.N.A.
|
19.7 dB(A) |
|
Static pressure
|
2.56 mm Hâ‚‚O |
|
Static pressure with L.N.A.
|
1.3 mm Hâ‚‚O |
|
Input power (max.)
|
2.28 W |
|
Max. input current
|
0.19 A |
|
Operating voltage
|
12 V |
|
MTTF
|
> 150,000 h |
|
Scope of delivery |
NF-A14x25 G2 PWM PPA |
| NF-A14x25 G2 PWM PPB | |
| 2x NA-RC16 Low-Noise Adaptor (L.N.A.) | |
| NA-YC1 4-pin PWM splitter cable | |
| 2x NA-EC1 30cm extension cable | |
| 8x NA-AV2 anti-vibration mounts | |
| 2x NA-AVG2-LR anti-vibration gasket for water cooling radiators | |
| 8x NA-AVP1-LR load-relief anti-vibration pads | |
| Fan screws | |
|
Warranty
|
6 years |
