Description
Quick Specifications
| | |
Manufacturer Specifications
|
FAN Specification | |
|
Size
| 120x120x25 mm |
|
Mounting hole spacing
| 105×105 mm |
|
Connector & pin-configuration | 4-pin PWM |
|
Cable length
| 2cm + 30cm NA-EC1 extension cable |
|
Bearing
| SSO2 |
|
Blade geometry
|
A-Series with Flow Acceleration Channels |
|
Frame technology
|
AAO (Advanced Acoustic Optimisation) |
|
Material
|
Sterrox® LCP |
|
Rotational speed (+/- 10%)
| 2000 RPM |
|
Min. rotational speed @ 20% PWM (+/-20%) | 450 RPM |
|
Airflow
| 102,1 m³/h |
|
Acoustical noise
| 22,6 dB(A) |
|
Static pressure
| 2,34 mm H₂O |
|
Input power (typical)
| 1,2 W |
|
Input power (max.)
| 1,68 W |
|
Input current (typical)
| 0,1 A |
|
Max. input current
| 0,14 A |
|
Operating voltage
| 12 V |
|
Voltage PWM signal | 5 V |
|
MTTF
| > 150.000 h |
|
Scope of delivery
| 4x NA-AVP1 chromax.black anti-vibration pads |
| 4x NA-AVP1 chromax.blue anti-vibration pads | |
| 4x NA-AVP1 chromax.green anti-vibration pads | |
| 4x NA-AVP1 chromax.red anti-vibration pads | |
| 4x NA-AVP1 chromax.white anti-vibration pads | |
| 4x NA-AVP1 chromax.yellow anti-vibration pads | |
| 4x NA-AVP1 grey anti-vibration pads | |
|
NA-AVG1 chromax.black anti-vibration gasket for water cooling radiators | |
| Fan screws | |
|
Warranty
| 6 years |
