Description
Quick Specifications
| | |
| | |
| | |
Manufacturer Specifications
| Usage Application | Client PCs, PlayStation® 5 | |
| Interface | PCIe® 5.0 x4, NVMe™ 2.0 | |
| Hardware Information | Capacity[1] | 1TB |
| Controller | Samsung in-house Controller | |
| NAND Flash Memory | Samsung V-NAND TLC | |
| Cache Memory | 1GB LPDDR4X | |
| Dimension | Max 80.15 x Max 22.15 x Max 2.38 (mm) | |
| Form Factor | M.2 (2280) | |
| Performance (Up to.)[3,4,5] | Sequential Read | 14,700 MB/s |
| Sequential Write | 13,300 MB/s | |
| QD 256 Thread 32 | Ran. Read | 1,850 KIOPS |
| Ran. Write | 2,600 KIOPS | |
| Active6) (Avg.) | Read | 7.6 W |
| Write | 7.2 W | |
| Idle (Typical) | PS3(APST on) | 4.0 mW |
| PS4 (L1.2) | 3.3 mW | |
| Temp. | Operating |
0°C to 70°C (Measured by S.M.A.R.T. Temperature Proper airflow recommended) |
| Non-Operating | -40°C to 85°C | |
| Humidity | 5% to 95% non-condensing | |
| Shock | Non-Operating | 1,500G(Gravity), duration: 0.5ms, 3 axis |
| Vibration | Non-Operating | 20~2,000Hz, 20G |
| MTBF | 1.5 million hours | |
| TBW | 600 TB | |
| Warranty[7] | Period | 5 years limited |
| Supporting Features | TRIM (Required OS support), Garbage Collection, S.M.A.R.T | |
| Data Security |
AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667) | |
1) 1GB = 1,000,000,000 bytes by IDEMA. A certain portion of capacity may be used for system file and maintenance use, thus the actual available capacity
may differ from the labeled capacity.
2) The 8TB model complies PCI-SIG® D5 standard specification. Please check the specifications of the host device before installation.
3) 9100 PRO is backward compatible with PCIe 4.0 x4 and 3.0 x4.
4) Sequential and random performance measurements are based on FIO 3.33. Performance may vary based on SSD’s firmware version, system
hardware & configuration. Test System: AMD Ryzen 9 7950X 16-Core Processor CPU@4.50GHz, DDR5 4800MHz 16GBx2, OS-Ubuntu 22.04.2,
Chipset-ASRock-X670E-Taichi.
5) Sequential and random write performance was measured with Intelligent TurboWrite technology being activated. Intelligent TurboWrite operates only
within a specific data transfer size. For detailed information, please contact your local service center.
6) Active power consumption is measured on FIO 3.33 with AMD Ryzen 5 7600 6-Core Processor CPU@3.80GHz, DDR5 4800MHz 16GBx2, OS-Ubuntu
22.04.3 LTS, Chipset-ASUS ProArt X670E-CREATOR WIFI STCOM.
7) All documented endurance test results are in compliance with JESD218 Standards. Please visit www.jedec.org for detailed information on JESD218
Standards. TBW means Terabytes Written, Warranty provides coverage for the stated time period or the TBW, whichever comes first. Please refer to the
detailed warranty statement here at //www.samsung.com/samsungssd
may differ from the labeled capacity.
2) The 8TB model complies PCI-SIG® D5 standard specification. Please check the specifications of the host device before installation.
3) 9100 PRO is backward compatible with PCIe 4.0 x4 and 3.0 x4.
4) Sequential and random performance measurements are based on FIO 3.33. Performance may vary based on SSD’s firmware version, system
hardware & configuration. Test System: AMD Ryzen 9 7950X 16-Core Processor CPU@4.50GHz, DDR5 4800MHz 16GBx2, OS-Ubuntu 22.04.2,
Chipset-ASRock-X670E-Taichi.
5) Sequential and random write performance was measured with Intelligent TurboWrite technology being activated. Intelligent TurboWrite operates only
within a specific data transfer size. For detailed information, please contact your local service center.
6) Active power consumption is measured on FIO 3.33 with AMD Ryzen 5 7600 6-Core Processor CPU@3.80GHz, DDR5 4800MHz 16GBx2, OS-Ubuntu
22.04.3 LTS, Chipset-ASUS ProArt X670E-CREATOR WIFI STCOM.
7) All documented endurance test results are in compliance with JESD218 Standards. Please visit www.jedec.org for detailed information on JESD218
Standards. TBW means Terabytes Written, Warranty provides coverage for the stated time period or the TBW, whichever comes first. Please refer to the
detailed warranty statement here at //www.samsung.com/samsungssd
based on 122 ratingsThis score is based on all expert and user reviews that TestFreaks has collected for this product. Reviews and scores are collected from more than 30 countries but only reviews in selected languages are shown below.
| 5 | ☆ | |
| 4 | ☆ | |
| 3 | ☆ | |
| 2 | ☆ | |
| 1 | ☆ |
- User Reviews (68)
- Write Review
Powered by TestFreaks
JD
Very fast! 1.5 GB transfer to another nvme pcie 4, took 1.5 seconds!
easy to install
none
WA
Performance great and stable on Asrock amd 870e motherboard, In Be Quiet 901 pro case.
fast
A little toasty, 40 to 50 c. Good case airflow required
