Description
Quick Specifications
| | |
Manufacturer Specifications
|
FAN Specification
| |
|
Size
| 40x40x20 mm |
|
Mounting hole spacing | 32×32 mm |
|
Connector & pin-configuration
| 4-pin PWM |
|
Cable length
| 20cm + 30cm NA-EC1 extension cable |
|
Bearing
| SSO2 |
|
Blade geometry
|
A-Series with Flow Acceleration Channels |
|
Frame technology
| AAO (Advanced Acoustic Optimisation) |
|
Rotational speed (+/- 10%) | 5000 RPM |
|
Rotational speed with L.N.A. (+/- 10%) | 4400 RPM |
|
Min. rotational speed @ 20% PWM (+/-20%) | 1200 RPM |
|
Airflow
| 9,4 m³/h |
|
Airflow with L.N.A.
| 8,3 m³/h |
|
Acoustical noise
| 14,9 dB(A) |
|
Acoustical noise with L.N.A. | 12,2 dB(A) |
|
Static pressure
| 2,26 mm H₂O |
|
Static pressure with L.N.A. | 1,75 mm H₂O |
|
Input power (typical) | 0,46 W |
|
Input power (max.) | 0,6 W |
|
Input current (typical) | 0,04 A |
|
Max. input current | 0,05 A |
|
Operating voltage | 12 V |
|
Voltage PWM signal
| 5 V |
|
MTTF
| > 150.000 h |
|
Scope of delivery | Low-Noise Adaptor (L.N.A.) |
| 4-pin y-cable | |
| 30cm extension cable | |
| OmniJoin™ adaptor set | |
| NA-AV3 anti-vibration mounts | |
| Fan screws | |
|
Warranty
| 6 years |
