Description
Quick Specifications
|
|
|
Manufacturer Specifications
| Compatibility | Intel LGA1851/1700/1200/115X/20XX |
| AMD AM5/AM4 | |
| TDP |
200W |
|
Overall Dimension |
128×73×152mm (L×W×H) |
|
Heatsink Material |
4×Ф6mm Heatpipe (Direct Touch) + Aluminum Fin |
| Weight |
550g (heatsink+fan) |
|
Fan Model |
AS-120-RGB V2 |
|
Fan Dimension |
120×120×25mm |
|
Fan Speed |
300 ~ 2000±10% RPM |
|
Max. Air Flow |
58CFM |
|
Max. Static Pressure |
1.94mmH2O |
| Noise |
27.2dB(A) Max. |
|
Rated Voltage |
12VDC (4-pin PWM) |
|
Operating Voltage |
10.8 ～ 13.2VDC |
|
Started Voltage |
7VDC |
|
Rated Current |
0.2A |
|
Power Input |
2.4W |
|
Bearing Type |
Hydraulic Bearing |
|
Connector |
4-pin PWM |
| EAN |
6931393308203 |
