Description
Quick Specifications
|
|
|
|
|
|
Manufacturer Specifications
| LCD SCREEN | |
|
System Requirement |
Windows 10, Windows 11 |
| Dimension | 1.48 inch |
| Resolution | 240×240 px |
| Backlight | 300cd/m² |
| Color | 18-bit, 262K |
| Compatibility | Intel LGA1851/1700/1200/115X |
| AMD AM5/AM4 | |
| TDP | 350W |
|
Radiator Dimension |
396×120×27mm |
|
Radiator Material |
Aluminum |
| Tube Material | Premium Sleeved Tubing |
| Tube Length | 420mm |
|
Waterblock Dimension |
73x69x57mm |
|
Cold Plate Material |
Copper |
| Pump Current | 0.45A Max. |
| Pump Speed | 2900RPM±10%(PWM) |
| Pump Bearing | Ceramic Bearing |
|
Pump Life Expectancy |
50,000 Hrs |
|
Pump Noise Level |
25dB(A) |
| Fan Model | AS-120-ARGB V2 |
| Fan Dimension | 120×120×25mm |
| Included Fans | 3pcs |
| Fan Speed | 300～2000±10%RPM |
| Max. Air Flow | 58CFM |
|
Max. Static Pressure |
1.94mmH2O |
| Noise | 27.2dB(A) Max. |
| Rated Voltage | 12VDC |
|
Operating Voltage |
10.8～13.2VDC |
|
Started Voltage |
7VDC |
| Rated Current | 0.15A |
| Power Input | 1.8W |
| Bearing Type | Hydraulic Bearing |
| Connector | 7-pin (4-pin PWM + 5V 3-pin ARGB) |
