Description
Quick Specifications
|
|
|
|
|
|
|
|
|
Manufacturer Specifications
| Net Weight | 1632 g |
| Radiator Dimensions | 402×120×27 mm(L×W×H) |
| Radiator Material | Aluminum |
| Tube length | 410 mm(L×W×H) |
| Pump Dimensions | 91×78×65 mm(L×W×H) |
| Pump Speed | 2500~3400 RPM±10% |
| Pump Connector | 4-pin PWM |
| Pump Rated Voltage | 12 VDC |
| Pump Rated Current | 0.29 A |
| Pump Power Consumption | 3.48 W |
| Fan Dimensions | 120×120×25 mm(L×W×H) |
| Fan Speed | 500~2100 RPM±10% |
| Fan Airflow | 75.89 CFM |
| Fan Air Pressure | 2.53 mmAq |
| Fan Noise | ≤31.6 dB(A) |
| Fan Connector | 4-pin PWM |
| Bearing Type | Hydro Bearing |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.17 A |
| Fan Power Consumption | 2.04 W |
| LED Type | Addressable RGB LED |
| LED Connector | 3-pin(+5V-D-G) |
| LED Rated Voltage | 5 VDC |
| LED Power Consumption | 2.8 W（PUMP）/ 3.15 W（FAN×3） |
| EAN | 6933412729303 |
| P/N | R-LE360-WHAMMN-G-2 |
